Coating Selection

Based on the needs of Tangshan Special Vehicle Manufacturing Company, we recommend and provide the following two types of coatings:

1. Epoxy Zinc Phosphate Primer: This primer has excellent corrosion resistance and adhesion, suitable for the steel structure surfaces of tankers.

2. Acrylic Polyurethane Topcoat: This topcoat offers outstanding weather resistance, UV protection, and decorative effects, providing long-lasting appearance protection and aesthetics for tankers.

Technical Solutions

To ensure the best coating results, our company offers the following technical solutions:

1. Surface Treatment

Before coating, the steel surface of the tanker will undergo sandblasting to ensure the surface roughness reaches Sa2.5 level, removing all rust, oil, and other impurities, providing an ideal substrate surface for primer adhesion.

2. Primer Application

Using the Epoxy Zinc Phosphate Primer, we will apply the primer to the sandblasted steel:

- Application Method: High-pressure airless spraying will be used to ensure an even coverage of the paint film.

- Film Thickness: The thickness of a single layer of the paint film will be controlled at 60-80 microns to ensure adequate corrosion protection.

- Drying Time: Natural drying for 24 hours to ensure complete curing of the primer.

3. Topcoat Application

After the primer is fully dried, we will proceed with the application of the Acrylic Polyurethane Topcoat:

- Application Method: High-pressure airless spraying will be used to ensure a smooth and even topcoat.

- Film Thickness: The thickness of a single layer of the paint film will be controlled at 40-50 microns, with a total thickness of two layers reaching 80-100 microns.

- Drying Time: A 12-hour interval is required between each layer of application before proceeding to the next layer, with a final natural drying time of 48 hours.

Project Implementation

Throughout the entire coating process, our technical team will be involved, providing on-site guidance and technical support to ensure the coating quality meets standards. We will regularly check and evaluate the coating results to ensure that each step is strictly executed according to the plan.

Project Outcomes

Through this collaboration, the surface coating quality of the tankers produced by Tangshan Special Vehicle Manufacturing Company has significantly improved, achieving the expected corrosion resistance and aesthetic effects. Specific outcomes include:

- Significant Corrosion Resistance: The Epoxy Zinc Phosphate Primer provides excellent corrosion protection, effectively extending the service life of the tankers.

- Outstanding Weather Performance: The Acrylic Polyurethane Topcoat offers long-term UV and climate protection, keeping the tankers in good condition even in harsh environments.

- Lasting Aesthetics: The high-gloss topcoat enhances the appearance of the tankers and is durable, resisting fading.

Customer Feedback

Tangshan Special Vehicle Manufacturing Company has expressed high recognition of the coating products and technical support provided by our company, and has indicated that it will continue to collaborate with us to further enhance product quality and market competitiveness.

Summary

Through this successful collaboration, our company has not only demonstrated high-quality coating products and professional technical support capabilities but has also strengthened the partnership with Tangshan Special Vehicle Manufacturing Company. In the future, we will continue to be committed to providing customers with superior coating solutions, helping them achieve higher product quality and market competitiveness.
